Middle connection

Factory of tubular

radiators

Radiator

The middle connection on the tubular radiator is used for connection to pipes from the floor, from the wall, and for the combination of heating with radiators and underfloor heating.

Colors

Installation

Characteristics

Colors

Installation

Characteristics

other products

Accompanying program

Factory of tubular radiators Expansion vessel support NEŠA KOMERC vessel holder can be used to mount the bowl on the wall or on another vertical

With heater

We also offer dryers with the option of installing an electric heater, filled with distilled water and thermofluid. The strength of the heater depends on

NK STANDARD

The “NK STANDARD” radiator is a tubular radiator that, due to its shape and design, takes up very little space, the main purpose of which

NK TERM 22

This radiator is made of welded steel pipes (Ч 0146), of material DC01 in standard EN 10305-3, EN 10305-5, of “D” profile with dimensions of

Height H (mm)	Width W (mm)	Connection distance E (mm)	Number of tubes	Weight (kg)	Cubage (L)	Thermal performance 75/65/20℃ ΔT 50 K	Thermal performance 55/45/20 ℃ ΔT 30 K	Connection dimensions G (col)
800	400	350	14	3,72	3,00	277	145	1/2
1000	400	350	16	4,53	3,77	342	179	1/2
1200	400	350	20	5,34	4,54	404	212	1/2
1500	400	350	22	6,46	5,36	495	260	1/2
1800	400	350	26	7,58	6,18	583	307	1/2
1500	400	350	27	7,08	5,72	527	277	1/2
1800	400	350	33	8,58	6,84	654	346	1/2
800	550	450	14	4,34	3,45	332	174	1/2
1000	500	450	16	5,30	4,29	410	215	1/2
1200	500	450	20	6,25	5,13	486	255	1/2
1500	500	450	22	7,59	6,05	594	314	1/2
1800	500	450	26	8,93	6,97	696	369	1/2
1500	500	450	27	8,25	6,56	637	336	1/2
1800	500	450	33	9,99	7,89	787	415	1/2
800	600	550	14	4,96	3,89	387	203	1/2
1000	600	550	16	6,06	4,80	479	252	1/2
1200	600	550	20	7,17	5,71	567	299	1/2
1500	600	550	22	8,72	6,74	692	367	1/2
1800	600	550	26	10,27	7,77	809	431	1/2
1500	600	550	27	9,41	7,40	747	395	1/2
1800	600	550	33	11,41	8,93	919	485	1/2
800	700	650	14	5,58	4,34	442	232	1/2
1000	700	650	16	6,83	5,32	547	288	1/2
1200	700	650	20	8,08	6,30	648	343	1/2
1500	700	650	22	9,85	7,43	791	420	1/2
1800	700	650	26	11,62	8,56	922	493	1/2
1500	700	650	27	10,58	8,24	858	454	1/2
1800	700	650	33	12,82	9,98	1051	555	1/2
